Mahsulot tavsifi:

Tang bilan Morse konusli Drill Chuck Arbor asosan asboblarni samarali mahkamlash va dastgoh asboblaridan foydalanish doirasini kengaytirish uchun burg'ulash chucklarini ulash uchun torna va frezalash mashinalarida qo'llaniladi.

product-723-513

product-400-372 product-465-372

1.Oson o'rnatish, material mustahkam, sindirish oson emas.

2.Matkap chuck bilan, zaxira burg'ulash chuck tutqichi sifatida foydalanish mumkin.

3.Yuqori navli asbob po'latdan yasalgan

4.Kafolatlangan eng yaxshi mumkin bo'lgan aniqlik va moslik.

5.Individual tarzda qadoqlangan.

6.Qattiqlashtirilgan va nozik tuproq.

Foydalanish bo'yicha ko'rsatmalar:

product-578-214

Birlashtiruvchi rodning uzun uchi (burg'ulash mashinasiga ulangan va hokazo): U mashina shpindel teshigining konusiga to'g'ri kelishi kerak, aks holda undan foydalanish mumkin bo'lmaydi. Tanlovni o'lchash va solishtirish uchun kaliperdan foydalanishingiz mumkin.

Birlashtiruvchi rodning qisqa uchi (burg'ulash chuckiga ulangan): Kerakli burg'ulash diametri bo'yicha mos keluvchi siqish diapazonini tanlagandan so'ng, chuck konusning interfeysiga ko'ra tanlang.

Spetsifikatsiya

product-927-390

Model	d% 2fmm	L% 2fmm	Model	d% 2fmm	L% 2fmm	Model	d% 2fmm	L% 2fmm
MS% 7b{0}% 7dB10	10.094	86	MS% 7b{0}}B22	21.793	147	MS% 7b{0}}J3	20.599	114
MS% 7b{0}}B12	12.065	90	MS% 7b{0}}B24	23.825	157	MS% 7b{0}}J4	28.550	125
MS% 7b{0}}B16	15.733	97	MS% 7b{0}% 7dB10	10.094	145	MS% 7b{0}}J5	35.890	130
MS1-B18	17.780	105	MS% 7b{0}}B12	12.065	149	MS% 7b{0}}J6	17.170	108
MS% 7b{0}}B22	21.793	114	MS% 7b{0}}B16	15.733	156	MS% 7b{0}}J1	9.754	118
MS% 7b{0}}B24	23.825	124	MS% 7b{0}% 7dB18	17.780	164	MS% 7b{0}}J2	14.199	124
MS% 7b{0}% 7dB10	10.094	101	MS% 7b{0}}B22	21.793	172	MS% 7b{0}}J3	20.599	133
MS% 7b{0}}B12	12.065	1205	MS% 7b{0}}B24	23.825	182	MS% 7b{0}}J4	28.550	144
MS% 7b{0}}B16	15.733	112	MS% 7b{0}}J1	9.754	85	MS% 7b{0}}J5	35.890	149
MS% 7b{0}% 7dB18	17.780	120	MS% 7b{0}}J2	14.199	90	MS% 7b{0}}J6	17.170	127
MS% 7b{0}}B22	21.793	128	MS% 7b{0}}J3	20.599	99	MS% 7b{0}}J1	9.754	143
MS% 7b{0}}B24	23.825	138	MS% 7b{0}}J4	28.550	110	MS% 7b{0}}J2	14.199	149
MS% 7b{0}% 7dB10	10.094	120	MS% 7b{0}}J5	35.890	116	MS% 7b{0}}J3	20.599	158
MS% 7b{0}}B12	12.065	124	MS% 7b{0}}J6	17.170	94	MS% 7b{0}}J4	28.550	169
MS% 7b{0}}B16	15.733	131	MS% 7b{0}}J1	9.754	100	MS% 7b{0}}J5	35.890	174
MS% 7b{0}% 7dB18	17.780	139	MS% 7b{0}}J2	14.199	105	MS% 7b{0}}J6	17.170	152

Tegishli mahsulot

Drill Chuck Arbor R8 dastani, to'g'ridan-to'g'ri shpal va morse konusli dastani o'z ichiga oladi.

Ishlab chiqarish jarayoni

product-671-428

Qadoqlash va jo'natish

PAKET: Standart eksport kartonli qadoqlash.
Etkazib berish muddati: Buyurtma tasdiqlanganidan 3-20 kun o'tgach, batafsil etkazib berish sanasi ishlab chiqarish mavsumi va buyurtma miqdoriga qarab belgilanishi kerak.

product-750-736
